Unifiltech Multi-Membrane-Clean depth Pleat cartridges are specially designed for absolute particle removal efficiency in classification and clarification applications. All polypropylene cartridge combine the advantages of depth filter and Pleat filter. This results in the super long service life and absolute particle removal efficiency.
● The combination of the advantages of depth filter and Pleat filter provides super long service life and absolute particle removal efficiency.
● The special Pleat construction, offering large surface area, provides as much as 2.3 times greater service life capacity than competitive filters.
● The depth construction enhances the dirt holding capacity which results in long service life.
● The unique construction provides the benefits in wide of final filtration as classification or clarification.
● The wide available ratings from 0.45μm to 40 μm is suit for most of applications.
● The all polypropylene construction provides wide chemical compatibility to suit for most of applications.
● Membrane: Polypropylene
● Parts: Polypropylene
● Sealing: melt seal process
● Maximum operation temperature: 175 ℉
● Maximum forward pressure drop: 42psi@77℉
● Maximum reverse pressure drop: 35psi@77 ℉
● Outside diameter: 66mm (2.65 inch)
● Surface area： 0.36 square meter(10 inch）
● Length (inch)：10，20，30，40
● Gasket/O ring：Silicone, Fluoroelastomer, Nitrile, EPR, FEP encapsulated Fluoroelastomer
● CMP
● Photoresist
● High purity chemicals
● Food & Beverage
● For detailed applications and filtration products, please contact Unifiltech Technical Supports and Sales Engineers.
