Unifiltech High-Pleat-Flow High Flow Cartridges are specially designed for the applications where the high flow capacity and absolute particle removal efficiency are required. The maximum flow rate per one element is up to 440 gpm. The cartridges are ideally suitable for PCW, pre-filtration, power generation and other applications
● Process Cooling Water (PCW)
● Pre-filtration
● Condensate Water
● Bottle Water
● Produced Water
● Waste Water
● Maximum operation temperature: 175 ℉
● Maximum forward pressure drop: 50psi@77℉
● Suggested change-out pressure drop: 35psi
● Outside diameter: 6 inch
● Rating (μm): 1; 2; 5; 10; 25; 40; 50; 75; 100
● Length (inch): 20; 40; 60
● Media: Polypropylene melt blow fibers
● Support layers: Polypropylene
● Cage: Polypropylene
● Parts: Polypropylene
● Gasket/O ring: Silicone; Nitrile; EPF; Fluoroelastomer
