● Multi-layer media design provides graded-density media which selectively trap the particles throughout element. This result in high loading capability, super long service life and reduced filtration cost.
● The cartridges characterize absolute particle removal efficiency which provides  consistent and repeatable filtration performance to ensure the fluid quality
● The Membrane-Clean WA cartridges offer high flow rate with low initial pressure drop, resulting in the outstanding throughput, reduced Vessels investment and filter consumption.
● The Membrane-Clean WA cartridges feature advanced  unsymmetrical  “W” pleating technology that increase more than 20% of surface area than competitive filters, providing longer service life.
● All Polypropylene  construction provides wide chemical compatibility and thermal stability. The cartridges are suited for most of applications
● The cartridges are available with absolute rating from 0.2 micron to 70 micron to meet customer filtration selections.

● Display
● UPW
● Food & Beverage
● Purity chemicals
● Coating & Ink
● Air filtration

● Membrane: Polypropylene (PP)
● Cage, Core: Polypropylene (PP)
● Supporting layers: Polypropylene (PP)
● Gasket/O ring：Silicone, Fluoroelastomer, Nitrile,  EPR, FEP encapsulated silicone, PP
● Sealing: melt seal process

● Maximum operation temperature: 175℉
● Maximum forward pressure drop:60psi@77 ℉
● Maximum reverse pressure drop: 40psi@77 ℉
● Outside diameter: 68mm (2.67inch)
● Surface area: 0.7 square meter
● Length (inch)：9.75, 10, 19.5, 20, 29.25, 30, 39, 40
